14" CUT-OFF SAW
MXF314-2XC
Sign Up To Receive Updates On MX FUEL™ Equipment
MX FUEL™ 14" Cut-Off Saw Kit
INSTANT START, ZERO EMISSIONS
FASTEst CUTS FROM START TO FINISH
6 FT IN CONCRETE, 72 CUTS IN #5 REBAR PER CHARGE
specifications
Full 14" Cut Capacity
14" capacity gives you the ability to cut up to 5" depths in every application and finish the job with fewer passes. A 20mm/1" arbor adapter is included to maximize versatility and prevent wasted time searching for a compatible blade.
ONE-KEY™ Compatible
Track, manage and secure equipment from your mobile device or computer using the industry’s largest Bluetooth® community tracking network. If ever lost or stolen, prevent tampering with remote lockout capability.
Onboard Water Connection
An onboard water connection allows you to use the saw for both dry and wet applications. A universal quick connect hose ensures simple and effective wet cutting in concrete/masonry applications.
Push Button Activation
The push button activation requires 97% less effort than a recoil start by eliminating the repetitive motions of a pull start. It allows you to start the saw in seconds every time, reducing down time so you can get the job done faster.
Wheels
Wheels on the front of the saw help create a straight, consistent cut with less strain.
- Battery Type
- Lithium-Ion
- Length
- 31.73 in
- Weight
- 32.1 lb
- Height
- 13.93 in
- Width
- 12.0 in
- Battery System
- MX FUEL™
- Blade Diameter
- 14"
- Cut Depth
- 5"
- RPMs
- 5350
- Blade Arbor Size
- 1"/20 mm
- Equipment Warranty
- 2 year
- Battery Warranty
- 2 year
- Push Button Activation
- Yes
- ONE KEY Compatible
- Yes
- Includes
- (1) Contractor Bag (1) Hex Key (1) MX FUEL™ 14" CUT-OFF SAW (2) MX FUEL™ REDLITHIUM™ XC406 Battery Pack (MXFXC406) (1) Quick Connect Collar (1) Wrench (1) MX FUEL™ CHARGER (MXFC)
- Downloads
- Download Operator’s Manual Download Service Parts List
BOTTOM LINE
A LIGHT USER is someone who uses a cut-off saw as a multi-purpose tool as needed. they cut mostly metals and plastics like corrugated decking, pvc pipe, cast iron, and rebar. they likely sub out most of their concrete cutting, but use a cut-off saw to do their own cuts in a pinch.
Example Application: A user who makes 2 cuts in rebar per day for 30 days out of the year is considered a light user.
A MEDIUM USER is someone who uses a cut-off saw as a multi-purpose tool regularly. they use a cut-off saw as their go-to tool for metals and plastics on site and do some of their own concrete/masonry cutting.
Example Application: A user who makes 30 cuts in rebar per day for 80 days out of the year is considered a medium user.
A HEAVY USER is someone who uses a cut-off saw consistently on site. They do a lot of heavy concrete and rebar cutting on a regular basis.
Example Application: A user who makes 90 cuts in rebar per day for 150 days out of the years is considered a heavy user.
Light Use
Medium Use
Heavy Use
A MEDIUM USER is someone who uses a cut-off saw as a multi-purpose tool regularly. they use a cut-off saw as their go-to tool for metals and plastics on site and do some of their own concrete/masonry cutting.
Example Application: A user who makes 30 cuts in rebar per day for 80 days out of the year is considered a medium user.
